Test / Extender Boards

Multilayer stub extender boards are designed to allow a 160mm daughter card to fit into a 220mm subrack system. Available for VME or as a DIN 96/96 way un-committed version.

Designed to bring cards out of a system for fault diagnostic or development work, these multilayer extenders provide jumper links for signal line interrogation, ejector levers and termination facility.

Available with or without the centre P0 connectors, these 6U multilayer extenders are for use in VME64x applications and are designed to bring cards out of a system for fault diagnostic or development work. Jumper links are provided on all signal lines for interrogation and an additional connector is fitted for connection to a logic analyser or termination module. Available separately is a metal frame to support the card and provide extraction functionality by two ejector levers.
